SSNC系列 耐腐蚀性系列节流阀
采用耐腐蚀性SUS316的节流阀，适于化学，医疗，半导体，太阳能电池，二次电池等领域；使用材料全部是无供油式样，可满足食品领域。
点击订货号查看价格，了解更多请登录，享受优惠请拨打4008-824-824
- 碧铄科(PISCO)
- -+
| 订货号 | 型号 | 一般 发货日 | 类型 | 工作压力范围 | 管子直径 | 螺纹 | 螺纹尺寸 |
|---|---|---|---|---|---|---|---|
| 114411 | SSNC4-01 | 耐腐蚀性 | 0~150psi(0~1MPa) | 4 | 锥管螺纹 | R1/8 | |
| 114412 | SSNC6-01 | 耐腐蚀性 | 0~150psi(0~1MPa) | 6 | 锥管螺纹 | R1/8 | |
| 114413 | SSNC8-01 | 耐腐蚀性 | 0~150psi(0~1MPa) | 8 | 锥管螺纹 | R1/8 | |
| 114414 | SSNC8-02 | 耐腐蚀性 | 0~150psi(0~1MPa) | 8 | 锥管螺纹 | R1/4 | |
| 114415 | SSNC10-02 | 耐腐蚀性 | 0~150psi(0~1MPa) | 10 | 锥管螺纹 | R1/4 | |
| 114416 | SSNC10-03 | 耐腐蚀性 | 0~150psi(0~1MPa) | 10 | 锥管螺纹 | R3/8 | |
| 114417 | SSNC12-03 | 耐腐蚀性 | 0~150psi(0~1MPa) | 12 | 锥管螺纹 | R3/8 | |
| 114418 | SSNC12-04 | 耐腐蚀性 | 0~150psi(0~1MPa) | 12 | 锥管螺纹 | R1/2 | |
| 114419 | SSNC16-04 | 耐腐蚀性 | 0~150psi(0~1MPa) | 16 | 锥管螺纹 | R1/2 | |
| 114420 | SSNC4-01-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 4 | 锥管螺纹 | R1/8 | |
| 114421 | SSNC6-01-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 6 | 锥管螺纹 | R1/8 | |
| 114422 | SSNC8-01-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 8 | 锥管螺纹 | R1/8 | |
| 114423 | SSNC8-02-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 8 | 锥管螺纹 | R1/4 | |
| 114424 | SSNC10-02-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 10 | 锥管螺纹 | R1/4 | |
| 114425 | SSNC10-03-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 10 | 锥管螺纹 | R3/8 | |
| 114426 | SSNC12-03-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 12 | 锥管螺纹 | R3/8 | |
| 114427 | SSNC12-04-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 12 | 锥管螺纹 | R1/2 | |
| 114428 | SSNC16-04-X | 耐腐蚀性 | 0~150psi(0~1MPa) | 16 | 锥管螺纹 | R1/2 | |
| 114429 | SSNC4-01-XTP | 耐腐蚀性 | 0~150psi(0~1MPa) | 4 | 锥管螺纹 | R1/8 | |
| 114430 | SSNC6-01-XTP | 耐腐蚀性 | 0~150psi(0~1MPa) | 6 | 锥管螺纹 | R1/8 | |
